ARMORSEAL 250
LIQUID JOINTLESS POLYURETHANE WATERPROOFING SYSTEM
Product Description
ARMORSEAL 250 is a revolutionary single component permanently elastic Polyurethane w a t e r p r o o fi n g m e m b r a n e w h i c h a f t e r p o l y m e r i z a t i o n f o r m s a n e l a s t o m e r i c polyurethane membrane, resisting UV rays and capable of handling building movement with a service life of 25 years.
Once cured ARMORSEAL 250 allows for expansion and contraction over a broad temperature range and maintain waterproofing properties under continuous exposure to water. It may be applied easily on different surfaces (concrete, mortar, brick, ceramics, bituminous membranes, steel, zinc, Aluminum).
- Excellent resistance to water and microorganism
- Resistant to temperature
- ARMORSEAL 250 membrane keeps its characteristics even in temperature between 500C to 100OC
- Waterproofed surface provides excellent weather resistance and UV resistance
- Provides sun reflectivity, contributing to thermo-insulation.
- It offers a seamless waterproofing system, allowing for easy localization of damage and
- High strength and puncture resistance and can adhere to almost any type of surface
- When applied it is jointless and no complicated detailing, therefore application is simple
- The waterproofed surface can be used for domestic, public pedestrian and vehicular traffic.
- Provides water vapor permeability, so the surface can
- Resistant to detergent, oil and other domestic chemicals
- Please note that ARMORSEAL 250 is a system not a product
ARMORSEAL 250 can be used for the waterproofing of concrete, tiles and metal surfaces such as:
- Roof
- Terraces and Balconies
- Planter boxes
- Retaining walls
- Wet areas in bathrooms under tile
- Foundations, Car parks. ETC
ARMORSEAL 250 can be applied to achieve different finish appearance. An anti-slip finish can be achieved by client if required, this involves introduction of aggregate at the second coat installation
Please ensure that hand gloves and goggles are worn during installation. ARMORSEAL contains isocynates, therefore apply in ventilated areas and away from flames. It is only important that during application and after application that standard safety procedure when handling all chemicals. Please consult current MSDS for product. For Professional Use only
All products should be stored in original packaging at temperatures between 5°C and 25°C. Protect products from all sources of heat, moisture, frost and direct sunlight. When opened product should be consumed immediately unless bucket can be sealed back without allowance for air. Shelf life for all products is 9 months maximum. Armorseal 250 is packed in 25kg pail
New concrete/ screed ,must be allowed to cure for 28 days. Adequate and detailed surface preparation is essential for durability of product after installation. Before application surface must be clean, dry and without contamination. The compressive strength of substrate must be at least 25MPa and cohesive bond strength must not be less than 1.5MPa.
All loose concrete, chirpings and dust should be removed, and uneven surface smoothened with the aid of grinding machine, the moisture content must be less than 5% Concrete cracks should be well cleaned and filled with a primer. Areas with large cracks must be paid special attention, they should be filled with ARMOR PU sealant and also covered with geotextile membrane after application of first coat.
PRIMING
Prime surface with ARMORFLO 500HD or ARMORPRIMER 200 to allow proper adhesion of membrane with substrate
APPLICATION OF ARMORSEAL 250
Armorseal 250 will be applied after priming in 2 coats. 2nd coat applied within 48 hours of first coat application.
APPLICATION OF TOPCOAT
Where the application of topcoat is required to achieve a complete treatment system for longer service life of 36 years, apply one or two layers of the ARMORSEAL 700 Top-Coat over the ARMORSEAL 250 Application of ARMORSEAL 700 is required where a heavy duty, abrasion resistant surface is desired (e.g. Public Pedestrian Deck, Car Parking, etc), apply two layers of ARMORSEAL 700 topcoat.
ARMORSEAL 250 can be applied to achieve different finish appearance. An anti-slip finish can be achieved by client if required, this involves introduction of aggregate at the second coat installation
Please ensure that hand gloves and goggles are worn during installation. ARMORSEAL contains isocynates, therefore apply in ventilated areas and away from flames. It is only important that during application and after application that standard safety procedure when handling all chemicals. Please consult current MSDS for product. For Professional Use only
PROPERTY | TEST METHOD | RESULTS |
Hardness (Shore A Scale) | ASTM D 2240 | 60 shore A |
Elongation At Break | ASTM D 412 / DIN 52455 | ≥ % 900 |
Tensile Strength | ASTM D 412 / DIN 52455 | ≥ 8 N/mm2 |
Water Vapor Permeability | ASTM E 96 | 0,8 gr/m2 sat |
Adhesion to Concrete | ASTM D 903 | ≥ 2N/mm2 |
Service Temperature |
| -40 °C to +80 °C |
Rain Stability Time |
| 4 hours |
Final Curing Time |
| 7 days |
